LBFS-03111.0

Manufacturer : Baumer
Description :
CleverLevel Point Level Measurement Sensor; SS Housing; Standard Approval; Power Supply: 12-30 Vdc; Electrical Connection: M12-A, 4-Pin, Stainless Steel without LED; Process Connection: G 1/2A ISO 228-1(G07), SS AISI 304 (1.4301); Output: PNP; Factory configured
Packaging Quantity : 1
Minimum Order Quantity : 1
Order In Multiples of Quantity : 1
Required Quantity :
- +
Price on Request

Product Salient Features:

  • Point level (Frequency Sweep) detection Sensor for Hygienic and Industrial applications
  • Wide variety of Process Connections
  • Optional Marine, ATEX, WHG and cULus approval
  • Compact and robust Stainless Steel housing
  • Reliable in diverse media
  • Process temperatures up to 200 Degree C
  • Economical Pricing
  • Ex-Stock Deliveries
Technical Data
Manufacturer : Baumer
Series : LBFS
Sensor Type : Level Measurement
Housing Material : Stainless Steel
Power Supply : 12-30 Vdc
Output : PNP
Electrical Connection : M12-A, 4-Pin, Stainless Steel without LED
Process Connection : G 1/2 A ISO 228-1 (G07)
Material of Process Connection : SS AISI 304 (1.4301)
Explosion Proof Protection : Standard
Configuration : Factory Settings
Gasket : Without
Protection : IP 67
