LBFI-21.010.G07020.1.0000.0

Manufacturer : Baumer
Description :
CleverLevel Point Level Measurement Sensor; with Programmable Output, IO-Link; Housing: Stainless Steel AISI 316L (1.4404); Power Supply: 8-36 Vdc; Electrical Connection: M12-A, 4-Pin, Polycarbonate with LED; Process Connection: G 1/2A ISO 228-1(G07), SS AISI 316L (1.4404); Without Gasket; Output: PNP; Without Ex-Proof; Standard Approvals; Factory configured
Packaging Quantity : 1
Minimum Order Quantity : 1
Order In Multiples of Quantity : 1
Required Quantity :
- +
Price on Request

Product Salient Features:

  • Point level (Frequency Sweep) detection Sensor for Industrial applications
  • Optionally with adaptive trigger
  • Optional ATEX and IECEx certified for dust and gas
  • Compact and robust Stainless Steel housing
  • Problem solver for adhesions
  • Two adjustable switching outputs
  • 360 Degree visible multicolor LED
  • IO-Link interface
  • Economical Pricing
  • Ex-Stock Deliveries
Technical Data
Manufacturer : Baumer
Series : LBFI
Sensor Type : Level Measurement
Version Type : Programmable O/p, IO-Link
Housing Material : SS AISI 316L (1.4404)
Power Supply : 8-36 Vdc
Output : PNP
Electrical Connection : M12-A, 4-Pin, Polycarbonate with LED
Process Connection : G 1/2 A ISO 228-1 (G07)
Material of Process Connection : SS AISI 316L (1.4404)
Explosion Proof Protection : Without
Industrial Approvals : Standard
Special Approvals : Standard
Configuration : Factory Settings
Gasket : Without
Protection : IP 67
